20KVA 15KW Three Phase Canopy Diesel Generator

Ask Lasest Price
Brand Name :	ACEPOW
Model Number :	APF-20
Certification :	CE,ISO, SASO
Price :	Negotiate
Payment Terms :	L/C, D/P, T/T
Supply Ability :	10000SETS/YEAR
Delivery Time :	25 DAYS

Add to Cart

Product Details
Company Profile

20KVA 15KW Three Phase Canopy Diesel Generator

Fawde Generator Set Pricelist Canopy Diesel Generator 20kva 15kw Ac Single Phase Three Phase Power Genset

Features :
Rated power: 5kVA-2500kVA
Frequency: 50/60Hz
Speed: 1500/1800rpm
Voltage: 110/220V, 230/400V, 220/380V
ATS (automatic transfer switch) receptacle
Stainless galvanized zinc plates with strong corrosion resistance
Base fuel tank for at least 8 hours running
Equipped with an industrial muffler
Engine oil pump
Complete protection functions and safety lables
Water jacket preheater, oil heater and double air cleaner, etc.

50hz @ 1500rpm or 60HZ @ 1800rpm all are available
Our Diesel Generator Engine for Choice
1. Cummins Engine 20KVA - 2000KVA
2. Deutz Engine 20KVA - 150KVA
3. FPT Iveco Engine 30KVA - 350KVA
4. Perkins Engine 8KVA - 2000KVA
5. Volvo Engine 85KVA - 700KVA
6. Doosan Engine 60KVA - 850KVA
7. Lovol Engine 20KVA - 150KVA
8.Yangdong Engine 8KVA - 40KVA
9. Weichai Engine 8KVA - 150KVA
10. Shanghai Engine 60KVA-1000KVA
11. Yuchai Engine 20KVA-1125KVA

Output Ratings

Generating Set Model	Prime	Standby

APX-20	20KVA/16KW	22KVA/18KW

Generating Set Model	Length (L) mm	Width (W) mm	Height (H) mm	Net kg (lb)	Gross kg (lb)

APX-20	1550	650	1050	520	570
APXS-20	1900	850	1100	700	750
Dry = With Lube Oil Wet = With Lube Oil and Coolant

MODEL	APF-20
PRIME POWER (KVA/KW)	20/16
STANDBY POWER(KVA/KW)	22/17.6
Rated voltage(V)	400/230
Rated speed(rpm)	1500
Rated frequency(Hz)	50
Power factor	0.8
Ambient temperature(℃)	40
Altitude(m)	1000
Connection type	3 phase 4 wires
ENGINE MANUFACTURER	FAWDE
Model	4DW91-29D
Rated Power(kW)	23
No. of cylinders & configuration	In-Line 4 cylinders
Method of operation	4-stroke
Speed regulation	Mechanical governor
Starting system	DC 12V Electronic start
Cooling method	Closed-circuit cooling system
Total displacement(L)	2.54
Compression ratio	17.0:1
BorexStroke(mm)	90 * 100
100% Load fuel consumption(L/h)	5

20KVA 15KW Three Phase Canopy Diesel Generator
