Outdoor 36KW 230V Single Phase Diesel Generator

    Buy cheap Outdoor 36KW 230V Single Phase Diesel Generator from wholesalers

    Buy cheap Outdoor 36KW 230V Single Phase Diesel Generator from wholesalers
    • Buy cheap Outdoor 36KW 230V Single Phase Diesel Generator from wholesalers
    • Buy cheap Outdoor 36KW 230V Single Phase Diesel Generator from wholesalers

    Outdoor 36KW 230V Single Phase Diesel Generator

    Ask Lasest Price
    Brand Name : ACEPOW
    Model Number : APIV-45
    Certification : CE,ISO, SASO
    Price : Negotiate
    Payment Terms : L/C, D/P, T/T
    Supply Ability : 10000SETS/YEAR
    Delivery Time : 25 DAYS
    • Product Details
    • Company Profile

    Outdoor 36KW 230V Single Phase Diesel Generator

    Fpt Iveco Engine Made In Italy Canopy Diesel Generator 36kw 45kva Outdoor Diesel Generator


    Features :


    • FPT IVECO engine

    • STAMFORD Alternator,Class H

    • Genset Canopy IP44 protection,Control panel IP56 protection

    • Control module Smartgen HGM6120N / DSE3110

    • Speed governor:Mech governor

    Canopy

    * All canopy designed with modular principles

    * All metal canopy parts painted by electrostatic polyester power paint

    * Soundproof design ensure that the noise level be controlled in small scope

    * Convenient to lift and move

    * Easy to maintenance and operate

    Base Frame

    * Base frame including position for forklift and crane

    * Integral fuel tank

    * Daily fuel tank continuously supply for 8-24 hours

    * Fuel tank easy to maintain and clean

    * Anti-vibration pads are flexed between engine and alternator.


    OUR ADVANTAGES

    1. Professional diesel engine generator set manufacturer

    2. 30 years of manufacturing and exporting experience

    3. Adopt International quality standards, to meet high quality requirement

    4. Good reputation for Reliable quality & Reasonable price

    5. Strong technical support

    6. Advanced production line with skilled workers


    Output Ratings
    Generating Set ModelPrimeStandby
    APIV-3645kVA/36kW50kVA/40KW

    Ratings and Performance Data
    Engine BrandFPT IVECO
    Engine ModelNEF45AM1A.S500
    Alternator BrandStamford
    Alternator ModelUC224C / UCI224C
    Control SystemSmartgen HGM6120N
    Circuit Breaker Type/
    Frequency / Phase50Hz/ Three phase
    Engine Speed ( RPM)1500Rpm
    Fuel Tank Capacity (L)210
    Fuel Consumption (L/h) (100% Load)17.1
    Model TypeOpen / Silent

    GENERAL
    Engine modelNEF45AM2.S500
    Prime power/ standby power kw41/45
    Number cylinders4
    Cylinder arrangementin linea
    Valves per cylinder2
    Speed governormechanical
    Injection systemdiretta
    Air intakeNA
    Bore mm104
    Stroke mm132
    Fuel System
    Fuel consumption at
    Stand-By gr/kWh (l/h) [kg/h]12.4 (225.7)
    100% load l/h (g/kWh)11.3 (222.3)
    80% load l/h (g/kWh)9.2 (228.6)
    50% load l/h (g/kWh)6.4 (235.9)
    Fuel specificationsEN 590
    Fuel pump max suction head m---
    Injection pump type STANADYNE
