    72KVA 3 Phase Standby Generator

    Ask Lasest Price
    Brand Name : ACEPOW
    Model Number : APYN-
    Certification : CE,ISO, SASO
    Price : Negotiate
    Payment Terms : L/C, D/P, T/T
    Supply Ability : 10000SETS/YEAR
    Delivery Time : 25 DAYS
    • Product Details
    • Company Profile

    72KVA 3 Phase Standby Generator

    Yunnei YN48GBZ Electricity Generator Standby Diesel Generator 55KVA 72KVA Standby Power Genset


    General features:

    Every generator set is subjected to a comprehensive test program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;

    24V DC start motor;

    Equipped 24V high performance maintenance-free lead-acid starting batteries and connecting with cables;

    Equipped with industrial silencer and flexible exhaust hose;

    Designed to Comply with ISO8528/GB2820;

    Powered by Cummins engine, Stamford alternator and DeepSea/ComAp/SmartGen control panel


    Control System
    Digital, intelligent control system allows easier operation.
    132*64 LCD display with backlight, optional language interface
    (Chinese, English, Spanish and Russian), push-button operation;
    Microprocessor control, with high stability and credibility
    Monitoring and measuring operational parameters of the mains supply and genset
    Indicating operation status, fault conditions, all parametersand alarms
    Multiple protections; multiple parameters display, like
    pressure, temp. etc.Manual, automatic and remote work mode selectable

    Yunnei YN Series Main Technical Specificiation
    NO.model

    item
    YN48GBZYN48GBZ
    1TypeWater cooling,in line,four-stroke,wet liner and direct injection
    2Number of cylinders4
    3Bore/Stroke mm108*132108*132
    4Displancement L4.84.8
    5Compression ratio18:1
    6Aspirationturboturbo
    7Rated output kW60/150077/1500
    8Rated speed r/min60/180077/1800
    9g/kW.h
    Fuel consumption rate
    ≦230≦230
    10%
    Steady speed adjusting rario at rated condition
    ≤5
    11Mpa
    Oil pressure
    0.25-0.35
    12r/min
    Idling speed
    800-850
    13Mpa
    Oil pressure at idle speed
    ≥0.10
    14g/kW.h
    Oil consumption rate
    2.72
    15L
    Oil sump capacity
    7
    16Starting methodElectric motor start
