250KW 313KVA 20A Electric Start Diesel Generator

Ask Lasest Price
Brand Name :	ACEPOW
Model Number :	APWC-250
Certification :	CE,ISO, SASO
Price :	Negotiate
Payment Terms :	L/C, D/P, T/T
Supply Ability :	10000SETS/YEAR
Delivery Time :	25 DAYS

Add to Cart

Product Details
Company Profile

250KW 313KVA 20A Electric Start Diesel Generator

Silent Diesel Generator 250KW Generator 313KVA Weichai Engine WP10D320E200 China Generator Supplier

AUSTRALIA SPECIAL DESIGN ADVANTAGE:
1. IP66 Australia special socket, 3 & 1 phase, 10A, 20A, 32A;
2. Australian industrial water-proof plug 1 & 3 phase
3. Double layer drawout design base fuel tank, anti- fuel leaking
4. Famous brand COMAP AMF20 controller
5. Weichai type engine , Brushless alternator with 100% copper
6. Forklift foot with Sockets for easy handling
7. Double lifting rings, removable, easy maintenance
8. Equip Superior quality "VARTA" battery
9. Base Fuel tank 360 L.
10. Stainless Steel all Screws, Nuts, Bolts and Door Locks & Hinges, Anti -rust

Control System
DKG116

FEATURES:
• Both Manual and remote control
• Generator protection
• Built in alarms and warnings
• Remote Start operation available
• True RMS measurements
• Tamper proof engine hours display
• Field adjustable parameters High current Fuel and
Crank outputs
• Optional auxiliary output
• Optional magnetic pickup input Digital inputs:4
• Survives cranking dropouts
• Sealed front panel
• Standard panel dimensions:96x48mm
• Plug-in connection system

Model	50Hz			Engine	Engine		Connector	Emission	Governor
	Generating Sets		Acepow		Prime
	Prime Power (KW)	Standby Power (KW)	Alternator		KW	KVA
APW-18	18	20	BC184E	WP2.3D25E200	23	29	4#7.5-104	T2	Mechanically
APW-18	18	20	BC184E	WP2.3D25E200	23	29	4#7.5-104	T2	Electronic
APW-24	24	27	BC184G	WP2.3D33E200	30	38	4#7.5-104	T2	Mechanically
APW-24	24	27	BC184G	WP2.3D33E200	30	38	4#7.5-104	T2	Electronic
APW-30	30	33	BC184H	WP2.3D40E200	36	45	4#7.5-104	T2	Mechanically
APW-30	30	33	BC184H	WP2.3D40E200	36	45	4#7.5-104	T2	Electronic
APW-36	36	40	UC224D	WP2.3D48E200	44	55	4#7.5-104	T2	Mechanically
APW-36	36	40	UC224D	WP2.3D48E200	44	55	4#7.5-104	T2	Electronic
APW-50	50	55	UC224E	WP4.1D66E200	60	75	3#11.5-128	T2	Mechanically
APW-50	50	55	UC224E	WP4.1D66E200	60	75	3#11.5-128	T2	Electronic
APW-64	64	70	UC224G	WP4.1D80E200	72	90	3#11.5-128	T2	Mechanically
APW-80	80	88	UC274C	WP4.1D100E200	90	113	3#11.5-128	T2	Electronic
APW-80	80	88	UC274C	WP4.1D100E200	90	113	3#11.5-128	T2	Electronic
APW-80	80	88	UC274C	WP2.3ND105E313	96	120	3#10	T3	Electronic
APW-100	100	110	UC274DS	WP3ND132E313	120	150	3#10	T3	Electronic
APW-80	80	88	UC274C	WP4D100E200	90	113	3#11.5	T2	Mechanically
APW-80	80	88	UC274C	WP4D100E200	90	113	3#11.5	T2	Electronic
APW-82	82	90	UC274C	WP4D108E200	98	123	3#11.5	T2	Electronic
APW-100	100	110	UC274DS	WP6D132E200	120	150	1#11.5	T2	Mechanically
APW-100	100	110	UC274DS	WP6D132E200	120	150	1#11.5	T2	Electronic
APW-120	120	132	UC274F	WP6D152E200	138	173	1#11.5	T2	Mechanically
APW-120	120	132	UC274F	WP6D152E200	138	173	1#11.5	T2	Electronic
APW-130	130	143	UC274F	WP6D167E200	152	190	1#11.5	T2	Mechanically
APW-150	150	165	UC274H	WP10D200E200	182	228	1#11.5/14-136	T2	Mechanically
APW-150	150	165	UC274H	WP10D200E200	182	228	1#11.5/14-136	T2	Electronic
APW-180	180	200	UC274J	WP10D238E200	216	270	1#11.5/14-136	T2	Mechanically
APW-180	180	200	UC274J	WP10D238E200	216	270	1#11.5/14-136	T2	Electronic
APW-220	200	220	HC434CS	WP10D264E200	240	300	1#11.5/14-136	T2	Mechanically
APW-220	200	220	HC434CS	WP10D264E200	240	300	1#11.5/14-136	T2	Electronic
APW-250	250	275	HC434DS	WP12D317E200	288	360	1#11.5/14-136	T2	Mechanically
APW-250	250	275	HC434DS	WP12D317E200	288	360	1#11.5/14-136	T2	Electronic
APW-250	250	275	HC434DS	WP10D320E200	290	363	1#11.5-136	T2	Mechanically
APW-250	250	275	HC434DS	WP10D320E200	290	363	1#14-136	T2	Electronic
