Three Phase 50KW 220V 1500RPM Brushless Alternator

Single Three Phase Brushless Alternator 50kw Synchronous Brushless AC Alternator Generator Head 1500Rpm 1800Rpm

Products description
1. Brushless synchronous alternator with Stamford technology.
2. Output range: 6.8kw - 1150kw single-phase and three-phase
3. High-performance Convenient installation and maintenance
4. Three phase 4 wire, optional 50Hz/60Hz, 1500/1800RPM
5. 4-pole, brushless alternator with AVR, H class insulation, IP23
6. Be suitable for various brands engine, international standard SAE port, double bearing as optional

Mechanic Features:
SHAFT AND KEY
All generator rotors are dynamically balanced to better than minimum vibration of BS6861: part1 grade 2.5 double bearings generators are banlanced with a half key.

ENGINE ADAPTOR AND COUPLING

All generators are designed two kinds of construction. The adaptor and the drive plate is consonant with SAE standard.

LEVELS Of PROTECTION

All generators are IP2 and IP23 and IP44 can be optional for aircool protected generator. but rated power will decrease 5~10%.

AP-224 series threephase synchronous brushless generator
Model	Rated Speed	50Hz 1500r/min				60Hz 1800r/min
	Insulation Class	Class H/Temp.(125ºC)				Class H/Temp.(115ºC)
	AstroSeries(V)	380	400	415	440	416	440	450	460	480
	AstroParallel(V)	190	200	208	220	208	220	225	230	240
	Triangle Series (V)	220	230	240	254	240	254	260	266	277

AP-224C	Rated Capacity(KVA)	42.5	42.5	42.5	40	50	52.5	52.5	52.5	55
	Rated Output(KW)	34	34	34	32	40	42	42	42	44
	Efficiency(%)	86.5	87.1	87.4	88.2	86.8	87.2	87.5	87.7	87.9
	Input Power(KW)	39.3	39	38.9	36.3	46.1	48.2	48	47.9	50.1
	Weight & Size	Net weight: 235kg Gross weight: 255kg Size: 1080mmx660mmx940mm

AP-224D	Rated Capacity(KVA)	50	50	50	48	60	62.5	62.5	62.5	65
	Rated Output(KW)	40	40	40	38.4	48	50	50	50	52
	Efficiency(%)	87.8	88.2	88.5	89	87.8	88.2	88.4	88.6	88.8
	Input Power(KW)	45.6	45.4	45.2	43.1	54.7	56.7	56.6	56.4	58.6
	Weight & Size	Net weight: 250kg Gross weight: 270kg Size: 1080mmx660mmx940mm
