Single Bearing 230KVA 1800RPM Brushless Alternator , AC Synchronous Alternator

AC Synchronous Brushless Alternator Single Bearing Brushless 230kva 250kva Three-Phase Alternator

ELECTRIC FEATURES
INSULATION AND VARNISH :
Insulation class H
All regulatory components are made up with special materials and are immersed in lacquer by peculiar tech.Varnish and colophony materials are developed to strengthen the processing and machinery intensity of windings and revolving parts for protecting the generator work under corrosive environment
WINDINGS AND ELECTRICAL PERFORMANCE :
2/3 pitch windings design can effectively eliminate the third harmonic wave(3rd,9th,15th)of the voltage,which is the best design of UPS for nonlinear load.Connected with the network in parallel,the structure can restrain excessive currents in the middle.A continuous damp windings abates surges The poles and gears of the windings are carefully chosen,this and the 2/3 pitch help to check the wave distortion of output voltage
TELEPHONE INFLUENCE FACTOR :
THF(defined by 40 th part of BS4999)<2%.TIF(defined by ASAC50.12)=<50.
RADIO INTERFERENCE :
Brushless apparatus and high quality AVR ensure little radio interference in transmission.RFI noise filter is also available

MODEL	Core Length	3-PHASE 50Hz /1500RPM 380V-440V		3-PHASE 60Hz /1800RPM 440V-480V		DIMENSION	WEIGHT
MODEL	Core Length	(KVA)	(KW)	(KVA)	(KW)	CM	KG
AP- 164A	L=65mm	8.1	6.5	10.2	8.2	64×54×72	95
AP- 164B	L=80mm	11	8.8	13.8	11	64×54×72	102
AP- 164C	L=100mm	13.5	10.8	16.9	13.5	64×54×72	110
AP- 164D	L=115mm	16	12.8	20	16	64×54×72	116
AP- 184E	L=150mm	22.5	18	28.8	23	84×59×75	133
AP- 184F	L=190mm	27.5	22	34.4	27.5	84×59×75	156
AP- 184G	L=230mm	31.3	25	37.5	30	84×59×75	172
AP- 184H	L=255mm	37.5	30	46.9	37.5	84×59×75	226
AP- 184J	L=285mm	40	32	50	40	84×59×75	236
AP- 224C	L=134mm	42.5	34	52.5	42	96×66×102	275
AP- 224D	L=160mm	50	40	62.5	50	96×66×102	295
AP- 224E	L=186mm	60	48	70	56	96×66×102	315
AP- 224F	L=248mm	72.5	58	87.5	70	96×66×102	345
AP- 224G	L=309mm	85	68	97.5	78	96×66×102	385
AP- 274C	L=165mm	100	80	118	94	126×76×102	415
AP- 274D	L=205mm	114	91	138	110	126×76×102	435
AP- 274E	L=230mm	140	112	168	134	126×76×102	485
AP- 274F	L=285mm	160	128	190	152	126×76×102	530
AP- 274G	L=340mm	175	140	213	170	126×76×102	580
AP- 274H	L=375mm	200	160	245	196	126×76×102	630
AP- 274J	L=410mm	230	184	281	224.8	130×76×102	750
