5KVA Air Cooled Standby Generator

Home Use Standby Generator 5kw 5kva 5000watts Single Cylinder Air Cooled Diesel Generator Diesel Engine Genset

Features:

Genset model: AP6000SE

5KVA rated output

China made 10HP diesel engine AP186FA
China made 100% copper wire alternator

Its advanced direct fuel injection system adopting minimized pump

nozzle insures long life and provides for low fuel consumption,easy starting,quiet running.
Silent canopy, portable and mobile type
Fuse circuit breakers for overload protection and convenience.
Four wheels ensure easy moving

Portability and operation indoors or outdoors.
Electric start with 30AH battery
Silent canopy with 4 wheels ensure easy moving;
Best designed muffler; portable model for home use.

Digital meter,digital controller , ATS (automatic transfer switch)

Sound-absorbing panels keep lower noise.

GENERATOR	Model	AP6500SE
	Frequency(HZ)	50	60
	Max. output(kw)	5	5.5
	Rated output(kw)	4.6	5
	Rated. AC voltage(v)	120, 220, 230, 240, 380, 400
	Power factor(cosΦ )	cosΦ =1
	DC output (v)	12V/8.3A
	Phase	Single phase or Three phase
	Alternator type	self-excited
	Starting system	Electric
	Operating noise level(at 7m)	68-72DB
	Fuel tank capacity(L)	16
	Continues work(hr)	9.4	8.4
ENGINE	Model	AP186FA
	Engine type	Single cylinder, vertical, 4-stroke air-cooled diesel engine
	Bore× stroke(mm)	86× 72
	Fuel	0# or -10# light diesel fuel
	Lubrication oil volume(L)	1.65
	Combustion system	Direct lnjection
STANDARD FEATURES	Voltmeter	yes
	AC Output Socket	2
	AC circuit breaker	yes
	Oil warning light	yes
	Oil alert	yes
OPTIONAL FEATURES	DC circuit breaker	optional
	Calculagraph	optional
	Big Wheel	optional
	Three phase voltage	optional
	Current meter	optional
	ATS	optional
	Remote control	optional
	Welding	no
DIMENSIONS	Dimension(L× W× H)(mm)	950× 560× 710
	Net weight(kg)	147
	20FT	72
