    1500RPM 200KVA 160KW Prime Power Diesel Generator

    Fpt Iveco Diesel Powered Generator 160kw 200kva Prime Power Diesel Generator Closed Cooled Power Genset


    Features :

    • FPT IVECO engine

    • STAMFORD Alternator,Class H

    • ATS receptacle

    • Lockable battery isolator switch

    • Powder coated canopy

    • Vibration isolators between engine/Alternator and base frame

    • Integrated wiring design

    • High water temperature protection

    • Steel base frame with forkslots

    • Big daily fuel tank

    Canopy
    * All canopy designed with modular principles
    * All metal canopy parts painted by electrostatic polyester power paint
    * Soundproof design ensure that the noise level be controlled in small scope
    * Convenient to lift and move
    * Easy to maintenance and operate


    Output Ratings
    Generating Set ModelPrimeStandby
    APIV-160200kVA160kW220kVA/176kW
    Ratings and Performance Data
    Engine BrandFPT IVECO
    Engine ModelNEF67TM7.S500
    Alternator BrandStamford
    Alternator ModelUC274H / UCI274H
    Control SystemSmartgen HGM6120N

    GENERAL
    Engine modelNEF67TM7.S500
    Prime power/ standby power kw177/195
    Number cylinders6
    Cylinder arrangementin linea
    Valves per cylinder2
    Typediesel 4 tempi
    Injection systemdiretta
    Induction SystemTurbo aftercooler aria/aria
    Bore mm104
    Stroke mm132
    Total displacement lit6.7
    Mean piston speed m/s6,6
    Compression ratio17,5 : 1
    Flywheel rotationantiorario
    Housing flywheelSAE 3
    Flywheel11''1/2
    Fuel System
    Fuel consumption at
    Stand-By gr/kWh (l/h) [kg/h]199(47.5) [39.7]
    full load PRP gr/kWh (l/h) [kg/h]193 (42) [35]
    Lubrication System
    Oil sump capacity
    max liter12
    min liter8
    Oil system capacity including filters liter17.2
