Emergency Power Isuzu Diesel Powered Generator 50kva 40kw 4bd1-Z 4 Cylinder Closed Water Cooling Power Generators

Product description

Rated power: 5kVA-2500kVA
Frequency: 50/60Hz
Speed: 1500/1800rpm
Voltage: 110/220V, 230/400V, 220/380V

Engine Brand: ISUZU

Number of Cylinders: 6

Cylinders Arrangerment: Vertical in-line

Aspiration: Turbo & Inter cooler

Starting method: Electric motor start

Type : 6-cylinder,In-line,Water cooled,Four-stroke,Turbo & Inter cooler

Governing Type: Mech

Governor Regulation

Coolant Capacity (L): 30

Rotation direction (face to the flyweel): Anticlockwise

The lowest stable speed at zero load (r/min): ≦ 1000

Starting motor capactiy (V.kw): 24V 3.7KW

Charging generator capactiy (V.A): 28V 35A

Accumulator capacity (V.Ah): 24V 120Ah

Alternator: ACEPOW Brushless alternator

Conttrol System: Separaately Excited BY P.M.G.

Insulatiion System : Class H

Protection: IP23

Rated Power Factor: 0.8

Stator Winding: Double Layer Concentric

Winding Pitch: Two Thirds

Winding Leads : 12

Exciter Rotorr Resisttance: 0.091 Ohms Per Phase At 22°C

R.F.I. Suppression: BS EN 61000-6-2 & BS EN 61000-6-4,VDE 0875G, VDE 0875N. refer to factory for others

Type: Super-silent, silent, open, mobile, container type

Optional: ATS, water heater, fuel heater...

Controller: Deepsea,Smartgen, Datakon

Delivery time: within 20 days

Export port: Fuzhou, China

Warranty: Running 1000 hours or 12 months

Fijian Acepow Equipment Co.,Ltd is located in fuan,fujian,China. It’s special at manufacturing diesel generator set, diesel alternator and motor product. Now our factory, covers an area of 50000 square meters, and have gotten ISO9001 and ISO4001 certificate. Our diesel genset have passed CE, SASO, SONCAP certificate.

Now our mainly brand for generator set is Cummins, Perkins, Deutz, Isuzu, Weichai, Shangchai, Yangdong, Quanchai and so on. And our alternator mainly brand conclude Stamford, Leroy somer, Marathon, Mecc alte.

Our mainly exporting market is South-east Asia,South-America,MID-east,South-Asia,Africa and so on. Acepow will be your best power supplier!

ACEPOW Disesel Generating Sets is the product of full experienced engineers designing series of modern generators which is applicable for construction or for back-up power.

The ACEPOW generators has a unique, compact design using the most reliable diesel engine in China featuring low fuel consumption, low maintenance cost, long life, easy to operate and transport.

Our Diesel Generator Engine for Choice
1.Cummins Engine 20KVA - 2000KVA
2.Deutz Engine 20KVA - 150KVA
3.FPT Iveco Engine 30KVA - 350KVA
4.Perkins Engine 8KVA - 2000KVA
5.Volvo Engine 85KVA - 700KVA
6.Doosan Engine 60KVA - 850KVA
7.Lovol Engine 20KVA - 150KVA
8.Yangdong Engine 8KVA - 40KVA
9. Weichai Engine 8KVA - 150KVA
10. Shanghai Engine 60KVA-1000KVA
11. Yuchai Engine 20KVA-1125KVA

Canopy for Choice
1. Silent type (75- 80 dB(A) at 7 meters)
2. Super Silent type (65-70 dB(A) at 7 meters )
3. Open type
4. Trailer type (mobile)
5. Container Type
6. Parallel System
