China Cheap Generators Diesel Powered Generator 106kva 85kw
6bg1-Zl1 Isuzu Silencer Noise Reduction Genset Canopy
Main product and power range
1. Diesel generator 5-2500KVA
2. AC alternator 2-2500KVA
Engine Brand: ISUZU
Number of Cylinders: 6
Cylinders Arrangerment: Vertical in-line
Aspiration: Turbo & Inter cooler
Coolant Capacity (L): 30
Rotation direction (face to the flyweel): Anticlockwise
The lowest stable speed at zero load (r/min): ≦1000
Starting motor capactiy (V.kw): 24V 3.7KW
Charging generator capactiy (V.A): 28V 35A
Accumulator capacity (V.Ah): 24V 120Ah
Alternator: ACEPOW Brushless alternator
Conttrol System: Separaately Excited BY P.M.G.
Insulatiion System : Class H
Protection: IP23
Stator Wdg.Resistance: 0.044 Ohms Per Phase At 22°C Series Star
Connected
Rotor Wdg.Resistance: 1.26 Ohms at 22°C
Exciter Stator Resiistance: 20 Ohms at 22°C
Exciter Rotorr Resisttance: 0.091 Ohms Per Phase At 22°C
R.F.I. Suppression: BS EN 61000-6-2 & BS EN 61000-6-4,VDE 0875G,
VDE 0875N. refer to factory for others
Control System
* Control, monitor and protect the Generator Set including:
* High water temperature
* Low oil pressure
* Over and under speed
* Over current
* Under/Over generator voltage
* Start and stop failure
* Low and high battery voltage
* Charge fail
* Emergency stop
| Output Ratings |
| Generating Set Model | Prime |
|
| API-106 | 106KVA/85KW |
| Dimensions and Weights |
| Generating Set Model | Length (L) mm | Width (W) mm | Height (H) mm |
|
| API-106 | 2200 | 900 | 1450 |
| APIS-106 | 2920 | 1080 | 1670 |
| Dry = With Lube Oil Wet = With Lube Oil and Coolant |
| Ratings and Performance Data |
| Engine Brand | ISUZU |
| Engine Model | 6BG1-ZL1 |
| Alternator Brand | Stamford |
| Alternator Model | UC274D / UCI274D |
| Control System | Smartgen HGM6120N |
| Circuit Breaker Type | / |
| Frequency / Phase | 50Hz/ Three phase |
| Engine Speed ( RPM) | 1500Rpm |
| Generator set Manufacture | Acepow |
| Oil Consummption (g/kW.h) | ≦ 0.4 |
| Volatage (V) | 220/230/240 |
| Silencer Noise Reduction (dBA) | 10-20 |
| Engine Technical Data |
| Engine Model | 6BG1-ZL1 |
| Engine Brand | ISUZU |
| Number of Cylinders | 6 |
| Cylinders Arrangerment | Vertical in-line |
| Bore/Stroke (mm) | 105*125 |
| Speed (RPM) | 1500 |
| Displacement (L) | 5.885 |
| The lowest stable speed at zero load (r/min) | ≦ 1000 |
| Starting motor capactiy (V.kw) | 24V 3.7KW |
| Charging generator capactiy (V.A) | 28V 35A |
| Accumulator capacity (V.Ah) | 24V 120Ah |
| Fuel Consumption: |
| API-113 | 100% Load | 75% Load | 50% Load |
| H/L | 28.10 | 21.07 | 14.05 |
| (Based on diesel fuel with a specific gravity of 0.85 and
conforming to BS2869,Class A2) |
